01
Supervision
- Monitoring and supervision of parametric circuits
- Data processing via multiple communication interfaces
- Transmission of calculation results to output devices
- Advanced control algorithm support
CUKS-7 - Digital Control and Monitoring Device
The CUKS‑7 Digital Control and Monitoring Unit is intended for controlling and monitoring industrial processes in hazardous areas where explosive atmospheres of gases, vapours, or dust may occur.
A rotating 3D model of the CUKS-7 industrial control unit is displayed. The device features a blue two-part enclosure. The lower section contains a monochrome display showing operating data, a red emergency stop button, a reader, and a row of multicolored alphanumeric buttons. Cable glands are mounted at the bottom of the enclosure. As the device slowly rotates, its design and components become visible from different angles. In the background, a blurred mining scene shows a conveyor belt transporting material and miners at work. The device remains the central focus throughout the animation.
// DESCRIPTION
What it is
The CUKS‑7 Digital Control and Monitoring Unit can operate either as a standalone device or as part of a digital network within a larger control system.
It features hands‑free communication, single‑strike signalling, diagnostic monitoring of selected voltages, as well as comprehensive control and monitoring capabilities.
The intrinsically safe design enables reliable operation in hazardous environments with potentially explosive gas and/or dust atmospheres.
CUKS-7 - Sterowanie, łączność, bezpieczeństwo
02
Communication
- Hands‑free voice communication
- Direct communication with a selected subscriber
- One‑to‑many group communication (1:N)
- Normal‑mode dispatcher calls
- Emergency dispatcher calls (ALARM mode)
03
Data Transmission
- Discrete digital inputs
- Analog outputs
- Voltage outputs
- Transmission line supervision
Applications of the CUKS-7
01
Supervision
- Supervision of control circuit parameters
- Alarm and warning signalling
- Monitoring and parameterization of input and output signals
- Remote management of individual devices, machines, and device groups
- Integration with a wide range of sensor types
02
Data Transmission
- Network node
- Hub
- PROFINET
- PROFIBUS
- MODBUS
Technical data
- ATEX Certificate Number
- FTZÚ 14 ATEX 0106
- Enclosure Protection Rating
- IP65
- Equipment Category
- M1
- Type of Protection
- Ex ia I Ma
- Supply Voltage
- 12,5 ÷ 15 VDC
- Maximum Supply Voltage
- 15,8VDC
- Supply Current
- < 150mA
- Operating Temperature Range
- 0 degC to +40 degC
- Relative Humidity
- Low humidity
- Gas Group
- I
// Gallery
Photos
// Classification
Category
Version
- Iskrobezpieczeństwo (Ex i)
- ATEX
- Ex
